MEAN WELL NDR-75-12

Mean Well NDR-75-12 is a slim DIN rail switching power supply designed for industrial automation, control systems, instrumentation equipment, and electrical panel applications. It provides a stable 12V DC output with a rated current of 6A and a total output power of 72W, making it suitable for PLC systems, industrial controllers, sensors, communication devices, and automation equipment.

The NDR-75-12 features a compact metal housing with slim DIN rail construction for TS-35 mounting, allowing efficient installation inside industrial control cabinets and automation panels. Its space-saving design is ideal for industrial environments where reliable power and compact installation are required.

The power supply supports a universal AC input range of 90–264VAC and a DC input range of 127–370VDC, ensuring compatibility with a wide range of industrial power systems. Designed for continuous industrial operation, the unit delivers high efficiency up to 88% while using free air convection cooling for silent and maintenance-free performance.

Built-in protection functions include short circuit, overload, overvoltage, and over-temperature protection to ensure safe and stable operation under demanding industrial conditions. The NDR-75-12 also includes a DC OK relay contact for remote monitoring and system diagnostics in automation systems.

With dependable industrial performance and durable DIN rail construction, the NDR-75-12 is widely used in factory automation systems, PLC control panels, industrial machinery, process control systems, instrumentation equipment, and electrical automation projects throughout Dubai and the UAE.

Technical Specifications

• Model: NDR-75-12
• Series: NDR-75
• Output Voltage: 12V DC
• Rated Output Current: 6A
• Rated Power: 72W
• Input Voltage Range: 90–264VAC / 127–370VDC
• Efficiency: Up to 88%
• Mounting Type: DIN Rail TS-35
• Cooling Method: Free air convection
• Housing Type: Slim metal enclosure
• Operating Temperature: -20°C to +70°C
• Protection Features:
  • Short circuit protection
  • Overload protection
  • Overvoltage protection
  • Over-temperature protection
• Additional Features:
  • DC OK relay contact
  • LED power indicator

Applications

• PLC automation systems
• Industrial control panels
• Factory automation
• Process control systems
• Instrumentation equipment
• Industrial communication devices
• Electrical automation cabinets
• Industrial projects in UAE
