Mean Well NTN-5K-248

Product Description

Mean Well NTN-5K-248 is a high-performance industrial-grade true sine wave DC-AC power inverter from Mean Well’s NTN-5K series. Delivering 5000W of continuous pure sine wave output from a 48VDC input, it provides clean, stable AC power for sensitive electronic equipment, critical industrial systems, backup power, telecom infrastructure, and renewable energy applications.

Key Specifications:

• Part Number: NTN-5K-248
• Brand: Mean Well
• Series: NTN-5K
• Type: DC-AC True Sine Wave Power Inverter
• Input Voltage: 48VDC (operating range: 40VDC – 66VDC)
• Output Power: 5000W continuous
• Output Voltage: 230VAC (supports 200/220/230/240VAC)
• Output Outlets: 1
• Output Waveform: Pure / True Sine Wave
• Efficiency: Up to 93%
• Built-in Function: AC Charger + UPS
• Operating Temperature: -30°C to +70°C
• Chassis: Silver, chassis mount
• Connection: Screw terminal block
• Certifications: TUV, CB, CE, FCC, EN, EAC, UKCA
