The MEANWELL SE-600-5 is an enclosed AC-to-DC switching power supply designed to deliver a regulated 5V DC output at up to 100A, with a rated output power of 500W. It is suitable for industrial electronics, high-current 5V equipment, LED displays, and applications requiring a stable, high-current DC power source. Featuring a metal enclosure, selectable AC input voltage, built-in cooling fan, and adjustable output voltage, this single-output power supply supports reliable operation in compatible industrial environments. Integrated protection functions help protect the power supply and connected equipment from electrical faults.
Brand: MEAN WELL
Model: SE-600-5
Product Type: Enclosed switching power supply
Rated Output Power: 500W
Output Voltage: 5V DC
Rated Output Current: 100A
Output Voltage Adjustment: 4.75–5.5V DC
AC Input Range: 90–132V AC / 180–264V AC, selectable by switch
Input Frequency: 47–63Hz
Typical Efficiency: 78%
Cooling: Built-in DC fan
Mounting: Chassis mounting
Dimensions: 247 × 127 × 63.5mm
Protection: Short circuit, overload, over voltage, and over temperature
Additional Feature: Built-in remote sensing function
High-current 5V DC equipment
Industrial automation systems
LED display systems
Electronic control equipment
Communication systems
Industrial testing equipment
Embedded electronics and power systems
