MEANWELL TDR-240-24

MEANWELL TDR-240-24

Dhs. 250.00
Dhs. 250.00
Sold out
Tax included.

MEANWELL TDR-240-24 is a 240W slim three-phase DIN rail switching power supply designed for industrial automation, control panels, machinery, and industrial control systems. It provides a regulated 24V DC...

Availability: Low stock: 3 left
SKU: OPX-ELC-0065
Vendor: MEAN WELL
Category: Unknown Type

Shipping & Returns

Free shipping and returns available on all orders!

We ship all US domestic orders within 5-10 business days

Care Instructions

We advise routinely dusting your items with a gentle cleanser to preserve its look. Periodically, it may need to be softly wet with a mild detergent solution.

View full product details

MEANWELL TDR-240-24 is a 240W slim three-phase DIN rail switching power supply designed for industrial automation, control panels, machinery, and industrial control systems. It provides a regulated 24V DC output at 10A and accepts a wide 340–550V AC three-phase input. It can also operate from 480–780V DC. The output is adjustable from 24–28V DC, with built-in protection and a DC OK relay contact for remote status monitoring.

Key Specifications

  • Brand: MEAN WELL
  • Model: TDR-240-24
  • Rated Power: 240W
  • Output Voltage: 24V DC
  • Output Current: 10A
  • Input Voltage: 340–550V AC, 3-Phase
  • DC Input: 480–780V DC
  • Frequency: 47–63Hz
  • Output Adjustment: 24–28V DC
  • Efficiency: 92%
  • Mounting: DIN Rail, TS-35/7.5 or TS-35/15
  • Cooling: Free-air convection
  • PFC: Built-in passive PFC
  • DC OK: Relay contact
  • Protection: Overload, overvoltage, overtemperature and short circuit
  • Dimensions: 63 × 125.2 × 113.5 mm
  • Operating Temperature: -30°C to +70°C
